C9200L-24PXG-4X-E Cisco Catalyst 9200 Series Switches C9200L 24-p 8xmGig, 16x1G, 4x10G, PoE+, Network Essentials

Name: C9200L24PXG4XE Cisco Catalyst 9200 Series Switches C9200L 24p 8xmGig 16x1G 4x10G PoE Network Essentials
Brand: CISCO
Price: 1 USD

Brand Name : CISCO

Model Number : C9200L-24PXG-4X-E

Certification : CE

Place of Origin : CHINA

Payment Terms : T/T

Delivery Time : 2-3 days

Model : C9200L-24PXG-4X-E

Description : C9200L 24-p 8xmGig, 16x1G, 4x10G, PoE+, Network Essentials

Switch capacity : 272 Gbps

Forwarding capacity : 214.28 Mpps

Number of ports : 24

Layer : 2

Manageable : yes

Stackable : yes

Rack Unit : /

Contact Now

C9200L-24PXG-4X-E Overview

C9200L-24PXG-4X-E is the 9200L 24-port (8xmGig, 16x1G), 4x10G, PoE+, Network Essentials. Cisco Catalyst 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise ?C it is secure, always on, and IT simplified.

Quick Spec

Table 1 shows the quick spec.

Model	C9200L-24PXG-4X-E
Downlinks total 10/100/1000 or PoE+ copper ports	24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G)
Uplink configuration	4x 10G fixed uplinks
Default primary AC power supply	PWR-C5-600WAC
Fans	Fixed redundant
Software	Network Essentials
Stacking bandwidth	80 Gbps
DRAM	2 GB
Flash	4 GB
Switching capacity	272 Gbps
Forwarding rate	214.28 Mpps
Chassis Dimensions	1.73 x 17.5 x 13.8 in 4.4 x 44.5 x 35.0 cm

Product Details

Catalyst 9200 series provides these highlights:

● Up to 48 ports of full Power over Ethernet Plus (PoE+) capability
● Resiliency with Field-Replaceable Units (FRU) and redundant power supply, fans, and modular uplinks
● Flexible downlink options with data or PoE+
● Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps
● UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure
● Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
● Layer 3 capabilities, including OSPF, EIGRP, ISIS, RIP, and routed access
● Advanced network monitoring using Full Flexible NetFlow

Cisco Software-Defined Access (SD-Access):

● Simplified operations and deployment with policy-based automation from edge to cloud managed with Cisco Identity Services Engine (ISE)
● Network assurance and improved resolution time through Cisco DNA Center
● Plug and Play (PnP) enabled: A simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or updates to an existing network
● Cisco IOS XE: A Common Licensing based operating system for the enterprise Cisco Catalyst 9000 product family with support for model-driven programmability and streaming telemetry
● ASIC with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries

Supported Products

Table 2 shows the recommended supported products.

StackWise-80 and StackWise-160 Kit and cables
Product number	Product description
C9200L-STACK-KIT=	C9200L Stack Kit Spare
STACK-T4-50CM	50CM Type 3 Stacking Cable
STACK-T4-1M	1M Type 3 Stacking Cable
STACK-T4-3M	3M Type 3 Stacking Cable
Power supplies
Product Number	Product Description
PWR-C5-600WAC/2=	600WAC power supply spare

Compare to Similar Items

Table 3 shows the comparison.

Model	Downlinks	Uplinks	Power Supply	Fans
C9200L-24PXG-4X-E	24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G)	4x 10G fixed uplinks	PWR-C5-600WAC	Fixed redundant
C9200L-48PXG-4X-E	48 ports full POE+ (12 mGig ports up to 10G, 36 ports up to 1G)	4x 10G fixed uplinks	PWR-C5-1KWAC	Fixed redundant
C9200L-24PXG-2Y-E	24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G)	2x 25G fixed uplinks	PWR-C5-600WAC	Fixed redundant
C9200L-48PXG-2Y-E	48 ports full POE+ (8 mGig ports up to 10G, 40 ports up to 1G)	2x 25G fixed uplinks	PWR-C5-1KWAC	Fixed redundant

C9200L-24PXG-4X-E Specification

C9200L-24PXG-4X-E Specification
Downlinks total 10/100/1000 or PoE+ copper ports	24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G)
Uplink configuration	4x 10G fixed uplinks
Default primary AC power supply	PWR-C5-600WAC
Fans	Fixed redundant
Software	Network Essentials
Chassis Dimensions	1.73 x 17.5 x 13.8 in 4.4 x 44.5 x 35.0 cm
Virtual Networks	1
Stacking bandwidth	80 Gbps
Total number of MAC addresses	16,000
Total number of IPv4 routes (ARP plus learned routes)	11,000 (8,000 direct routes and 3,000 indirect routes)
IPv4 routing entries	3,000
IPv6 routing entries	1,500
Multicast routing scale	1,000
QoS scale entries	1,000
ACL scale entries	1,500
Packet buffer per SKU	6 MB buffers for 24- or 48-port Gigabit Ethernet models
Flexible NetFlow (FNF) entries	16,000 flows on 24- and 48-port Gigabit Ethernet models
DRAM	2 GB
Flash	4 GB
VLAN IDs	1024
Total Switched Virtual Interfaces (SVIs)	512
Jumbo frames	9198 bytes
Wireless bandwidth per switch	N/A
Switching capacity	272 Gbps
Forwarding rate	214.28 Mpps
Mean time between failures (hours)	379,410

C9200L-24PXG-4X-E Cisco Catalyst 9200 Series Switches C9200L 24-p 8xmGig, 16x1G, 4x10G, PoE+, Network Essentials
